10
EL-Skyport triggers flashes without sync cords over a distance of
approximately 100 m. Further detailed information please find under
www.elinchrom.com / Products / RX Multi Remote
Open flash "Test"
Having pressed the touch pad to release a flash, the green «READY» light will
appear again once the unit is recharged. If the green light does not appear the
charge system could be defective.
Please contact and send to an authorized Elinchrom service.
Audible recharge signal
Select the function with the touch pad (8), the green indicator appears.
Once recycled an acoustic signal indicates that the compact unit is ready.
5
Test and Ready
8
Beep
EL-Skyport Universal Set
(19360)
Cordless flash control
The standard socket 3.5 mm mini-jack (6).
N.B. Do not link ELINCHROM units by cable to other manufacturers sync outlets.
ELINCHROM uses the low voltage (5V) for security reasons.
Sychronisation socket
Transmitter Universal receiver
