Description of machine
Operating screen
Water reservoir
Screwed feet
(with height
adjustment)
Loading door
(reversible)
Display panel
Large mesh filter
(lint filter)
Air slots
Lamp for interior
illumination
Rating plate
Base door
upstream of
heat exchanger
Micro-fine filter
(lint filter)
Fine strainer
(lint filter)
Programme progress display
Programme selector
Maintenance displays
– HEAT EXCHANGER (clean!)
– EMPTY WATER(empty!)
– CLEAN FILTER (clean fluff filter!)
Block of buttons
and displays
