14
To Replace:
1. Insert both hanger arms into the door.
2. Open the oven door.
You should hear a “click” as the door is set into place.
3. Move the hinge levers back to the locked position. Check
that the door is free to open and close. If it is not, repeat the
removal and installation procedures.
Storage Drawer
The storage drawer can be removed. Before removing, make sure
drawer is cool and empty.
To Remove:
1. Pull the storage drawer straight back past the drawer stop
notch and the end of the side rails.
2. Lift up the back of the drawer and pull the drawer out.
To Replace:
1. Lift up the back of the drawer and place it inside the range in
its fully forward position.
2. Lift up the front of the drawer to a level position.
3. Slowly push the drawer into the range until the drawer side
rails engage with the gap in the drawer glides.
4. Once the drawer is fully engaged on both sides, slide the
drawer back into the closed position.
NOTE: When you are removing and replacing the storage
drawer, a slight push may be needed to move the drawer
stop notch past the drawer glides.
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the
cost of an unnecessary service call.
Nothing will operate
■ Is the power supply cord unplugged?
Plug into a grounded outlet.
■ Has a household fuse blown, or has a circuit breaker
tripped?
Replace the fuse or reset the circuit breaker. If the problem
continues, call an electrician.
Cooktop will not operate
■ Is the control knob set correctly?
Push in knob before turning to a setting.
■ On coil element models, is the element inserted properly?
See “Coil Elements and Burner Bowls” section.
Excessive heat around cookware on cooktop
■ Is the cookware the proper size?
Use cookware about the same size as the surface cooking
area, element or surface burner. Cookware should not extend
more than ½" (1.3 cm) outside the cooking area.
Hot Surface indicator light stays on
■ Does the Hot Surface indicator light stay on after control
knob(s) have been turned off?
See “Cooktop Controls” section.
Cooktop cooking results not what expected
■ Is the proper cookware being used?
See “Cookware” section.
■ Is the control knob set to the proper heat level?
See “Cooktop Controls” section.
■ Is the appliance level?
Level the appliance. See the Installation Instructions.
■ On coil element models, is the element inserted properly?
See “Coil Elements and Burner Bowls” section.
Oven will not operate
■ On some models, has the oven selector been set to a
BAKE or BROIL function?
See “Baking and Roasting” or “Broiling” sections.
Oven temperature too high or too low
■ Does the oven temperature calibration need adjustment?
See “Oven Temperature Control” section.
Oven indicator lights flash
■ Do the OVEN HEATING indicator lights flash?
See “Assistance or Service” section.
A. Drawer stop notch
B. End of side rail
A. Engage drawer glide.
A
B
A
