Mount the two framing mount brackets on each side and secure the
fireplace to framing with screws or nails (refer to Figure 16). The brackets
will allow for a 1⁄2” (13 mm), 5⁄8” (16 mm), 3⁄4” (19 mm) thick finishing
wall. The wall may be finished up to the fireplace facing with combustible
material.
Figure 16. Nail Tab.
Initial Installation
QUALIFIED INSTALLERS ONLY
F
RAMING
M
OUNT
B
RACKETS
:
C
ORNER
I
NSTALLATION
:
The dimensions for installing a fireplace in the corner of a room are given in Figures 17 and 18. Refer to
“I
NITIAL
I
NSTALLATION
- V
ENT
C
ONFIGURATIONS AND
R
ESTRICTOR
S
ETTINGS
” for allowable pipe lengths.
Do not interfere with the structural integrity of the walls.
Figure 17. Dimensions for a corner installation, rear
vented.
15
Figure 18. Dimensions for a corner installation, top
vented.
R
AISED
F
IREPLACES AND
H
EARTHS
:
Figure 20. Raised Fireplace with Floor Level Hearth Figure 19. Raised Fireplace with Raised Hearth
