3
KEY
PART NUMBER
QTY
DESCRIPTION
REMARKS
GT-2000
1
10151448730
1
COVER, CYLINDER
2
10101147630
1
CYLINDER
S/N 001001 - 151953
2
10101106560
1
CYLINDER
S/N 151954 & UP
3
90016205022
2
BOLT, H.S. 5X22
4
10101044331
1
GASKET, CYLINDER BASE
USE KIT 88900042031
5
10000044330
1
PISTON KIT (S/N 001001 - 151953) INCLUDES ITEMS 6, 7, 8 & 10
5
10000048730
1
PISTON KIT (S/N 151954 & UP)
INCLUDES ITEMS 6, 7, 8 & 10
6
10001105330
1
RING, PISTON
S/N 001001 - 151953
6
10001105330
2
RING, PISTON
S/N 151954 & UP
7
10001311520
1
PIN, PISTON
8
10001504630
2
CIRCLIP, PISTON PIN
9
10001251230
1
BEARING, NEEDLE
10
10001411520
2
SPACER, PISTON PIN
11
------------------
1
CRANKCASE KIT (S/N 001001 - 151953) INCLUDES ITEMS 13, 14, 15 & 17
(USE SB1007)
11
------------------
1
CRANKCASE KIT (S/N 151954 & UP) INCLUDES ITEMS 13, 14, 15 & 17
(USE SB1007)
12
10021242030
2
OILSEAL
13
10021503930
2
PIN, DOWEL
14
90081036201
2
BEARING, BALL 6201
15
------------------
1
CRANKSHAFT
S/N 001001 - 151953 (USE SB1007)
15
------------------
1
CRANKSHAFT
S/N 151954 & UP (USE SB1007)
16
------------------
1
GASKET, CRANKCASE
USE KIT 889000 42031
17
90025304012
2
SCREW 4X12
18
90016205028
3
SCREW 5X28
19
89011548730
1
LABEL, MODEL
20
90025304016
2
SCREW 4X16
21
90056500005
2
NUT 5
22
90014205028
2
BOLT 5X28
23
90023804018
4
SCREW 4X18
24
10150348730
1
COVER, FAN (INCLUDES CLUTCH DRUM, BEARINGS & CIRCLIP)
25
90025305016
1
SCREW 5X16
26
15991248630
1
GUARD, TOP
ENGINE REPOWER
SB1007
1
SHORT BLOCK
INCLUDES FACTORY ASSEMBLED
CYLINDER, CRANKCASE, PISTON,
CRANKSHAFT, BEARINGS AND SEALS.
OPTIONAL
88900042031
1
GASKET KIT
10101044331
1
GASKET, CYLINDER BASE
------------------
1
GASKET, CRANKCASE
13001642031
1
GASKET, INTAKE
13001042031
1
GASKET, INTAKE
14586642031
1
GASKET, MUFFLER LID
14551042031
2
GASKET, MUFFLER
REVISED 09/99
ENGINE, EXTERNAL/INTERNAL/CRANKCASE/FAN HOUSING/COVER
