EVO3 MOTORIZED TREADMILL
Visit us at: www.evofitness.com
22
TRANSPORT INSTRUCTIONS
How to transport the treadmill:
1. To move the treadmill you will need to first flip
out the Right and Left Caster Brackets (38 and
2) located on the underside of the Left and
Right Uprights (28 and 29). You may need to
tilt the treadmill to one side in order to access
the wheels. Be careful when tilting the
treadmill because it is heavy. You may need
the assistance of another person to do this.
2. Be sure both Caster Brackets (38 and 2) are
flipped down and resting firmly on the floor as
shown in drawing 2.
3. Carefully lift the treadmill up slightly from the
rear and roll it to a desired position. Flip the
Caster Brackets (38 and 2) back up into their
stored position. Follow the instructions on the
STABILIZER ADJUSTMENT page in this
manual to level the frame to the floor.
