BES-1616/110 Rev. 2
8
5.2 Router mode
The BES-1616/110 router allows switching in different modes. You can chose among:
16x16 AES/EBU 1 Channel
8x8 AES/EBU 2 Channel
5x5 AES/EBU 3 Channel
4x4 AES/EBU 4 Channel
Switch 5 - 6 on the configuration switch set the router’s mode. The Triton Router Control software must
be configured according to the mode chosen on the router.
The modes can be switched according to the following pattern:
- means switch down
* means switch up
Switch 5 6 Mode
- - 16x16 AES/EBU 1 Channel
- * 8x8 AES/EBU 2 Channel
* - 5x5 AES/EBU 3 Channel
* * 4x4 AES/EBU 4 Channel
The printed nomenclature on the BES-1616/110 router is for use with 16x16 AES/EBU 1 channel. If one
of the other formats shall be used, please connect the audio signals according to the following tables.
Default mode is 16x16 AES/EBU 1 channel.
AES/EBU 1 Channel
Signal Input Signal Output
1 1 1 1
2 2 2 2
3 3 3 3
4 4 4 4
5 5 5 5
6 6 6 6
7 7 7 7
8 8 8 8
9 9 9 9
10
10 10 10
11 11 11 11
12 12 12 12
13 13 13 13
14 14 14 14
15 15 15 15
16 16 16 16
