1 General
The BES-3232/75 is a 32x32 AES/EBU digital audio router with unbalanced 75 Ohm in- and outputs.
This state of the art router provides high performance circuits in SMD technology for maximum system
performance. The BES-3232/75 is designed for all demanding routing tasks in digital studio and
broadcast environments. The built-in RS-232 interface allows the user to control the router via the Triton
Router Control System PC software with many operational features. The control bus allows linking the
unit to the BVS-3232 or BDS-3232 video router thus creating a 32x32 AFV router. Several units can be
combined to form a 2 or more layer AES/EBU matrix system. One or several Triton remote control
panels can control the BES-3232/75 as well. Another unique feature of the Triton 32x32 series is the
possibility to reconfigure the router via the configuration switch on the back plane so that the unit can be
several types of routers:
32x32 AES/EBU 1 Channel
16x16 AES/EBU 2 Channel
10x10 AES/EBU 3 Channel
8x8 AES/EBU 4 Channel
1.1 Specifications
Signal type: AES/EBU digital audio
Number of inputs: 32 unbalanced
Input impedance: 75 ohms
Number of outputs: 32 unbalanced
Output impedance: 75 ohms
Jitter: 950ps
Delay: 150ns
Signal level: > 0.2 - 7Vpp
Sampling rates: 32 - 96 kHz
Switching mode: digitally transparent
Audio connector: BNC
AC power: External power supply 100 - 260 VAC
DC power: ±5V, connector DB9 male
Dimensions: 483 x 44 x 280 mm (19”, 1RU)
