1 General
The BDS-1616 is a 16x16 serial digital video router with vertical interval switching. This state of the art
router provides maximum quality with a data rate of up to 360Mbps and automatic cable equalising on all
inputs. High performance circuits in SMD technology assure undiminished signal quality. The BDS-1616
is well suited for all demanding routing tasks in digital studio and broadcast environments. The built-in
RS-232 interface allows the user to control the router via the Triton Router Control System, with its many
operational features. The control bus technology allows linking the unit with the BAS-1616 or BES-1616
to create an AFV router. One or several Triton remote control panels can control the BDS-1616 as well.
Another unique feature of the Triton 16x16 series is the possibility to reconfigure the router via the
configuration switch on the back plane to create several formats of routers:
16x16 Serial Digital Video 1 layer
8x8 Serial Digital Video 2 layer
5x5 Serial Digital Video 3 layer
4x4 Serial Digital Video 4 layer
1.1 Specifications
Data rate NRZ: 143Mbps - 360Mbps
VIT input: Comp. Video 1Vpp, 300mV sync, 75 ohms
Number of inputs: 16 terminated
Equalisation: Automatic up to 250m (RG59)
Number of outputs: 16
Impedance: 75 ohms
Return-loss: > 16dB (10MHz-270MHz)
Signal level: 800mV fixed, 75 ohms load
Rise/fall time: typ. 0.7ns
Connector: BNC
AC power: External power supplies 100 - 260 VAC
DC power: +5V, connector DB9 male
Dimensions: 483 x 44 x 280 mm (19”, 1RU)
