1.2 Connection drawing
Configuration
switches
Input section Router Output section
NCB 1
Output connections Power connectors RS-232 port
VIT input
(not in use)
1 Network Control Bus. The protocol of this bus is equal, and compatible to the MIDI bus protocol.
