OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
Using Your Steam Cleaner with
Steam Pocket
1. Connect one of the extension
tubes to the hand grip on the flexible
steam hose. To attach the extension
tubes one onto the other or onto the
hand grip, press the locking button
ensuring that it fits into the hole.
(Fig. 4, Fig. 5) To disconnect, repeat
the operation by pressing the locking
button and pulling the two sections
apart.
NOTE: Fit the steam pocket frame with
the angle adapter onto the
extension tube.
6
5. Insert the electrical power cord into
the wall outlet. Heating time is
approximately 18 minutes with cold
water. Filling the steam generator
with hot water will shorten the heat up
time. Fig. 4
4. Bring the velcro strips that are on the
back side of the steam pocket towel
over the steam pocket frame and
attach to the inside of the front side of
the steam pocket towel. (Fig. 8)
2. To attach the steam pocket towel to
the steam pocket frame, slide the
steam pocket towel over the steam
pocket frame. (Fig. 6)
3. Bring the towel all the way to the
top of the steam pocket frame.
(Fig. 7)
WARNING: Always insure the
unit is “UNPLUGGED” from the
wall receptacle prior to attaching or
removing accessories.
Fig. 6
Fig. 7
Fig. 8
Step 8: Connect desired attachments
onto the flexible steam hose.
Step 9: Plug the unit into a standard (120
volt, grounded) wall receptacle.
Allow approximately 18 minutes
for vapor to reach its working
temperature and pressure. The
green ready light will illuminate
when the unit is ready for use.
Always point nozzle outlet in a
safe direction.
NOTE: When the steam cleaner has run
out of water, steam output will
cease.
Care & Maintenance of the Steam
Pocket Towel
Due to the unique cleaning ability of this
cloth, proper care of your micro fiber towel
is required to ensure long life and
continued cleaning ability.
• The first thing you should do when
you get a new micro fiber towel is to
wash and dry it. During the
manufacturing process the fabric has a
tendency to become flat as it picks up
contaminants from the air and
machinery. There will also be a number
of loose threads that, while they cause
no harm, can be annoying the first time
you use the towel.
• To clean the towel, simply wash it in your
washing machine using the warm water
setting.
• Always wash your towels separately
from other fabrics. They have a tendency
to pick up lint and other particles from
other fabrics and the next time you use
your towel, this lint will transfer to the
surface being cleaned.
• ONLY USE LIQUID DETERGENTS,
never use dry detergents as many times
the granules do not fully dissolve and
become trapped in the towel. This can
scratch the surface that you are
cleaning.
• NEVER USE BLEACH OR FABRIC
SOFTENERS! Bleach will damage the
micro fiber fabric and fabric softeners
deposit a coating on the micro fiber
fabric what will not allow the cloth to
clean efficiently.
• Air dry the towel. Do not put in a clothes
dryer as high heat will cause the towel to
shrink and the micro fibers to break
down.
• If you wash your towel on a regular basis
and don’t let them get too dirty, they will
last much longer. As with any fabric, dirt
particles, grease and other contaminants
can cause the fibers to break down,
therefore regular cleaning will help
preserve your micro fiber towels.
• As you use the micro fiber towel, you will
notice that sometimes a thread will
loosen or pull out. This is normal and
you should NEVER PULL AT THE
LOOSE THREAD! Pulling the thread can
cause the weave to come undone.
Instead, simply trim the thread with a
pair of sharp scissors.
Concentrator
Attach the concentrator to the handgrip
or to the extension tubes.
Then attach the bristle
brushes to the
concentrator.
Nylon Detail Brush (x2)
It is best for cleaning grout in-between
the tiles, ceramic and marble.
To use: Attach the nylon
detail brush on to the end
of the concentrator, which
then may be used directly
on the hand grip or with extension
tubes.
Extended Concentrator
Use the extended concentrator
to clean under toilet rims
or hard to reach places.
To use: Attach the extended
concentrator onto the handgrip or the
extension tubes.
7
Dual Edge Glass & Tile Squeegee
This attachment is very useful for
cleaning windows, plastic material,
ceramic, tiled or marble surfaces.
To use: Connect the tile
squeegee to the hand
grip or use with extension
tube for hard to reach
surfaces. Apply steam
abundantly, rub with the soft spongy
edge, then remove excess water and
dirt with the glass wiping edge.
IMPORTANT: When cleaning
windows, always avoid any sudden
changes in temperature to prevent glass
breakage or cracks.
Using the Variable Steam Feature
Your steam cleaner has a variable steam
feature that allows you to adjust the steam
flow to the job that you are doing. For
example, set the variable steam at lower
settings when using the window squeegee
and at higher settings when cleaning grout
seams. The variable
steam control is
located on the
handgrip. (Fig. 3)
To increase the
steam flow, turn
the knob counter
clockwise and to
decrease,
turn it
clockwise. Fig. 3
Attaching the Accessories to the
Handgrip
Fig. 5
