– 15 – ETAsys.com
Specifications are subject to change without notice.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800-321-6699 • Fax: 800-996-3821
ETA-20SH SPECIFICATIONS
General
Type
AC Power Conditioner & Suppressor Module
Power Requirements 120V 60Hz
Power Consumption .5W
RoHS Compliant Yes
Panel
Switched Outlets
Two, 20A
Spike & Surge Suppression H-N, N-G, H-G
Manual Override Slide switch
Extreme Voltage Shutdown (EVS) Below 101V or Above 132V AC Line (When Used With ETA-ECS6RM)
Connectors 5 Position Phoenix Euro Block Style
Fuse Protection 20A Slow Blow
DCV Remote Trigger 5 – 24DCV
Remote Trigger SPST Contact
Status Signals Output for Voltage and Current Data (All Signals are Low Voltage and Low Current)
Indicators Incoming AC, Active, AC Fault
Power Cord 9' (3M), 12-gauge NEMA 5-20P 125v AC plug
Technical Data
Current Rating
20 amps
Operating Voltage 102 to 132 VAC
High Voltage Surge Protection Trigger at 133VAC, 1ms Typically (When Used With ETA-ECS6RM)
Spike & Surge Suppression H-N, N-G, H-G
Low Voltage Protection Trigger 101 VAC, 1ms Typically (When Used With ETA-ECS6RM)
Spike Protection Modes Circuitry on Incoming AC Mains.
Minimum Spike Clamping Voltage 460 VRMS @ 3,000 amps
Maximum Spike Clamping Voltage 6000v
Maximum Spike Clamping Response Time 1 nanosecond
Spike Clamping Voltage @ 100A 1250Vp for 20µs
Maximum surge current 6,500 amps
Energy Rating @ 2ms 600 Joules
Noise Attenuation EMI/RFI Sequencer 10dB @ 10kHz, 40dB @ 100kHz, 100dB @ 10MHz
Temperature Range 5° to 35° C
Humidity Range 5% to 95% R.H.
Mechanical
Chassis Finish
Black
Mounting Side bracket adjustable
Dimensions 3.0" H x 8.5" D x 3.5" W (76mm x 216mm x 89mm)
Weight 5.5lbs (2.49kg)
Agency Listings MET (UL1449 Code)
ETA-20SH
AC Power Conditioning & Suppression Module
