Features & Specifications
(1) Features
n Comply with IEEE 802.3 10Base-2 and 10Base-T Ethernet Standards.
n Support eight RJ-45 connectors for 10Base-T connection and one 10Base-2 BNC
port for mixed media network environment.
n Built-in uplink port for easy connection to another hub using regular straight-
through cable.
n Complete sets of LEDs provide an easy diagnostic on the hub’s and individual
port’s status.
n Slim and Compact design
n Wall mountable
n Two-year warranty
(2) Specification
n Standards : IEEE 802.3
n 10Mbps Ports : RJ-45 x 8 & BNC x 1
n Hub LEDs : Power, Collision
n Port LEDs : RJ-45 -- Link/Activity, Partition
BNC - Activity, Partition
n Dimensions : 8.67 x 4.61 x 1.18 inches/220 x 117 x 30 mm
n Weight : 1.76 lb./800g
n Power : 6V DC, 0.7A external adapter
n Operating Temperature : 32-131 0 F (0-55 0 C)
n Operating Humidity : 10-95% (Noncondensing)
n Emission : FCC Class A & CE Mark
