8911 Instruction Manual

3

Specifications

The outputs feed a resistive network that performs three functions:

Attenuates the signal to become 1 volt peak-to-peak,

Creates a 75

output resistance matching the cable impedance, and

Limits the rise and fall times to meet the AES/EBU specification.

Linear Regulator

The voltage regulator is a monolithic integrated circuit with a fixed voltage
output of +5 volts. This regulator employs internal current limiting and
thermal shutdown.

Specifications

Table 1. 8911 Specifications

Parameter

Value

Input

Number

1 loopthrough

Signal type

AES/EBU digital audio, per AES3id:1995 and SMPTE 276M

Connector 75

BNC

Return loss

>25 dB, 0.1 to 6 MHz

Outputs

Number

8 reclocked

Signal type

AES/EBU digital audio, per AES3id:1995 and SMPTE 276M

Connector 75

BNC

Return loss

>25 dB, 0.1 to 6 MHz

Performance

Sample Rates

48KHz, 44.1KHz, and 32KHz (Automatic selection)

Environmental

Operating temperature range

0 to 45° C, noncondensing

Non-operating temperature range

-10 to +70° C, noncondensing

Power Requirements

Supply Voltage

+12 Volts

Power dissipation

3 Watts

Physical

Frame

Resides in standard 2 rack unit 8900 Series frame
