2. CEILING MOUNT 1. WALL MOUNT
DIMENSIONS
Unit(mm)
INSTALLATION
45 45
(Ø31.5) (Ø31.5) Ø2.7
Ø2.7
Ø46.5 Ø65
3-Ø3.5
Ø55
360˚
60˚ 60˚ 90˚
CONNECTION ANGLE OF VIEW
R (DC12V / DC5V)
DC12V/DC5V Regulated
Power Supply
DC12V/DC5V Regulated
Power Supply
B (GND)
Y (VIDEO)
BNC(RCA)
Video
Female Video in
Camera
Lead Wire Connection
DIY Cable Connection
Camera
TV
Monitor
TV
Monitor
TOP View
Front case
Lens Cable
Fixing screw
Fixture drum
Ceiling or Wall
Ball camera
1. Camera revoves 360˚
2. Camera ball is adjusted to max 60˚ from the
axis to each end of the front case.
3. Viewable angle of the camera lens is 90˚(Standard)
* 78˚ is available as an option.
1. WALL MOUNT
2. CEILING MOUNT
SIDE View
When you install the camera, please glue up the end of cable to
keep it stable in order to protect the camera from the humidity problems.
