Name
Description
1
Lens
Allows wide area to be monitored
2
Power Cable
Cable for Power source (DC 12V)
3
Ethernet Cable
Cable for Ethernet (PoE)
Connections
Installation
Carefully remove the contents from the box, and verity that nothing was
damaged in shipment.
1. Mark the screw hole positions on the ceiling or wall surface using the
Drilling Guide Label.
2. Disassemble the camera by removing the dome cover.
3. Mount the camera assembly using the Anchors (x2) and Screws (x2) to
the surface of the ceiling or wall.
