6.3.4 TRANSMISSION LINE PIN OUT
6.3.5 DC CONNECTOR PIN OUT
6.4 SWITCH SETTINGS
The switch is located under a removable panel on the rear of the unit.
Switch Down Up (default)
1
V54 loops
Enabled
RXD flashing
Enabled
Rate & Mode
buttons Enabled
Loop buttons
Enabled
2
3
4
V54 loops
Disabled
RXD flashing
Disabled
Rate & Mode
buttons Disabled
Loop buttons
Disabled
1 2 3 4
1
2
-48V
0V
3 CGND
2 1 3
1 2 3 4 5 6 7 8
1
3-8
2
Line A
Unused
Line B
