Ascaso – Ascaso Steel BAR User Manual

Page 10

STEEL BAR UM2id OK 2012.FH11 Mon Jun 04 16:49:04 2012 Página 10

on machine

- Group 2 button pad light goes out

- Stop pressing keys and switch off ma

chine

- Switch on again, the machine is ready

for the counter (default value 40 capsu

les)

To change counter value or

unprogramme

- Switch off the machine

- Press keys S-L-XL all at once and switch

on machine

- Group 2 button pad light and the S key

in group 1 go out

- Press S key to reduce number of

capsules or L key to increase. With each

press a key lights up with a value as

follows:

LED XL lit: 0 Switching off

unprogrammes machine

LED L lit: 35 capsules

LED XL and LED L lit: 40 capsules

LED S lit: 45 capsules

LED S and LED XL lit: 50 capsules

LED S and LED L lit: 55 capsules

- Select desired value and switch off

machine

- Switch on again, the machine is ready

with new value programmed

- On 5-key button pad, press S.-S..-XL

Preparation of coffee

Please, check your system:ground,pod

or capsule.

Ground

Any type of coffee may be used. For

optimum results, we recommend using

special "espresso" coffee blends as they

provide a suitable grind. If the coffee

comes out either very quickly or very

slowly, the type of coffee should be

changed for another finer or thicker grind

and tamping of the coffee should be

varied according to our recommendatio

ns.

1-. Switch on the machine using the

main switch 0/1 and place the filterholder

(with the filter) into the group.
2-. Wait for the pilot light

to switch

off (approx. 1.5 minutes). This means

the coffee machine has reached the

ideal temperature.Press coffee switch
XL

(continuos coffee) and let water

run out. Do this before making the coffee.

This will remove residue and balance

the temperature to create optimum wor

king conditions.

3-. Fill the coffee filter basket (1 or two

coffees according to requirements),

The filter must be filled to 3/4 of its

capacity, once pressed.(see picture )

4.- Clean off the remains of coffee that

have been deposited on the edges of

the filter basket so that it fits perfectly.

5-. Place the filter holder into the group

starting from the left and turning towards

the right with enough pressure at the

end. (see picture)

6-. Put the cups or cup on the grille and
switch on the coffee switch

-S(Short)/L

(large) -XL (Non-stop)

It takes 20/25 seconds to make an es

presso perfectly

Important: Tamped

The best espresso result are obtained

when the ground coffee is firmly tamped.

Monodose

Points 1 and 2 as in the section on

ground coffee.

Place the pod in the filter holder and

turn it gently to the right as far as it will

go. Do not exert force. Close gently.(see

picture )

Point 6 and notes as in the section on

ground coffee.

Capsule

Open the drawer

. Place the capsule

and close the drawer until the end. Place

the cup on the tray and press the desired
option on the keypad

. The perfect

extraction requires 20/25 seconds.
When the drawer

have 50 used cap

sules , the machine will alert flashing

the keypad. Once emptied and placed

again , will return to normal on mode.

Careful: Do not remove or turn

the filter holder while the water is passing

through as the appliance is at low pres

sure at this moment.

Notes:

1. The filter holder should always be

placed in the machine so that it remains

warm. Closed position.

2. Place the cups on the cup warmer

The right temperature (optimum

40ºC/105ºF) will improve the espresso

3. Coffee will continue to drip from the

spouts for a moment after the coffee

swich is turned off.

7 .

Preparation of cappuccino

Espresso base : 25 ml espresso co

ffee.Textured (frothed) & heated (ste

amed)

Milk : 125 ml cold and fresh milk ( 3-4

ºC).When you heat your milk for a ca

ppuccino it will be about: 55"C.Milk must

be fresh with fat at 3,2-3,5 %. Fill the

milk (only the right size por one cup.).

You must use a stainless steel jug .Fill

1/3 with milk

Creme : White color with brown border

produced by the espresso base. The

ideal density its uniform without bubbles.
Preparation : The manometer

will

indicate 1,2/1,5 bar. The boilerwill be

ready to serve steam and hot water (2o

minutes, aprox).

1) TEXTURE : making creme (Frothed

milk).

The milk texture that you need is descri

ascaso

ENGLISH

1 7
