1. A mounting template is included. Aquatic AV recommends using the ‘measure twice,
cut once’ method!
2. Once the mounting hole is complete, make sure the outside surface is clean and
clear of debris. The Media Player has an external water/dust proof gasket, but this
requires a clean and flat surface for best performance.
3. The Media Player has four (4) front screws. Drive the screws using a screw driver.
During final mounting apply equal pressure to all points for the best water/dust outer
seal performance. Make sure screws are snug and do not over tighten.
4. Review all outside surfaces of the Media Player to ensure a proper water/dust seal.
This is important for long-term environmental protection performance for your digital
media device.
1.5. Mounting Precautions
69.8mm
214.4mm
69.8mm
214.4mm
36.6mm
210.8mm
182.2mm
188.6mm
178mm
48.8mm
52.2mm
Getting Started
Media Player AQ-MP-5BT
