LEGEND: NS= Not Shown
** =Purchase locally
TLB 220, 225, 325, 425, and 535 P A R T S R E F E R E N C E
NO REQ’D PART NO DESCRIPTION
FRONT AXLE INSTALLATION PARTS A-6B
TLB 220 AND 325
TLB 225, 425, and 535
1 2 046425 M10-1.5 X 30 GRADE 10.9 BOLT
2 4 077066 7/16 WASHER, GRADE 8
3 1 046271 3/4 -16 NF X 6 GRADE 8 BOLT
4 2 15-000085 AXLE PIVOT SHAFT, THICK WASHER
5 2 320076 HYDRAULIC ADAPTER, 6400-06-06
6 2 042151 M10 SPLIT LOCK WASHER
7 2 042083 M10-1.5 HEX NUT
8 1 920209 3/4-16 NC CENTER LOCK NUT
9 1 10-000024 FRONT AXLE SUPPORT BRACKET
10 1 10-000032 FRONT AXLE ASSEMBLY WITH TIE ROD
NS 2 921229 FRONT AXLE BUSHING
1 2 046425 M10-1.5 X 30 GRADE 10.9 BOLT
2 4 077066 7/16 WASHER, GRADE 8
3 1 046271 3/4 -16 NF X 6 GRADE 8 BOLT
4 2 15-000085 AXLE PIVOT SHAFT, THICK WASHER
5 2 320076 HYDRAULIC ADAPTER, 6400-06-06
6 2 042151 M10 SPLIT LOCK WASHER
7 2 042083 M10-1.5 HEX NUT
8 1 920209 3/4-16 NC CENTER LOCK NUT
9 1 15-000032 FRONT AXLE SUPPORT BRACKET
10 1 10-000032 FRONT AXLE ASSEMBLY WITH TIE ROD
NS 2 921229 FRONT AXLE BUSHING
NO REQ’D PART NO DESCRIPTION
