TV Wall Server 1 System Administrator’s Manual
System Architecture
Within CMS system, a TV Wall Station acts as a CMS Client, it consists of a TV Wall Server
computer (where TV Wall server program is installed) and multiple monitors. As the TV Wall
service starts up, NVR Servers will be requested by CMS Server to stream video to TV Wall
Station.
However, with the purpose of pure real-time monitoring, a TV Wall Station is more like a
video recipient, for only live video and motion alerts are presented on TV Wall monitors; while
other operations such as video playback or PTZ control are performed via genuine CMS
Client interface (as Web Client or Workstation Client).
TV Wall Servers
TV Wall
System Control
NVR
Video Stream
Communication
CMS
