Installation Guide
3
Installation Procedures
This section describes the procedures in installing the camera directly on a dropped ceiling with
flat surface. Prepare a screwdriver and network cable for this installation; no additional
accessories are required. For simplicity, most of the camera images used in the succeeding
sections were taken using the camera model with heat sink; same procedures apply to the model
without heat sink unless specified.
Step 1: Unpack the Camera
NOTE: To avoid scratches or leaving fingerprints on the dome cover, it is recommended to retain
the plastic covering the dome cover until the camera is completely installed.
1. Slide the mounting plate counter-clockwise to detach it from the camera.
2. Remove the silicon bag.
