SPECIFICATIONS HC-245
SPECIFICATIONS
MODEL HC-245
Length 1342 mm (52.8 in.)
Width 251 mm (9.88 in.)
Height 212 mm (8.35 in.)
Weight (dry) 6.3 kg (13.89 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 32.2 mm (1.27 in.)
Stroke 26.0 mm (1.02 in.)
Displacement 21.2 cc (1.29 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-8Y (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X TM ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD, two-stroke,
air-cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl
alcohol or 15% MTBE. Do not use alternative fuels such as E-15 or E-85.
Oil Power Blend X TM Premium Universal 2-Stroke Oil
Fuel Tank Capacity 0.5 lit. (16.9 US fl. oz.)
Starter System Automatic Rrecoil Starter
Clutch Centrifugal Type
Gear Case Ratio 4.67:1
Cutter Single Edge
Length 971 mm (38.23 in.)
Pitch 35 mm (1.4 in.)
Height 23.0 mm (0.91 in.)
Maximum Diameter Cut
Soft Material 25.4 mm (1 in.)
Woody Material 13 mm (1/2 in.)
Idle Speed 3,300 RPM
Clutch Engagement Speed 5,100 RPM
Wide Open Throttle Speed (W.O.T.) 11,250 RPM
