9 92-0859 : Rev. 000519
Adjustable Centering Pin Kits for Elbow Mandrels
Maximum, minimum diameters
Pin Length
Pin
Length
Correct pin length is important for
rigidity. Use only the correct Contact
Pins specified for each head size.
"B" maximum diameter
"A" minimum diameter
