Model 200B Elbow Mandrel Pointer Kits
92-0344 : Rev. 961231
(For use with the Model 206B, BEVELMASTER
TM
)
Item
Part
No.
No.
Description
Qty
Parts List, Pointer Kit (P/N 05-0153)
1.
23-0228
ROD, INDICATOR
1
2.
30-0337
ROD, 1/4" DIA X 6
1
3.
30-0338
SLEEVE, CLAMP, 1/4"
1
46-0267
SLEEVE ASSY, ELBOW MDRL, 206B
1
4.
27-0364
ADAPTOR, SHAFT
1
5.
29-0007
BEARING, BALL
1
6.
33-0487
SCREW, SET, #10-24 X 3/16", CUP PT
1
7.
33-1750
SCREW, THUMB, BRASS, 1/4-20 X 1 1/2"
2
8.
46-0269
SLEEVE, INDICATOR
1
(For use with the Model 212B, BEVELMASTER
TM
)
Item
Part
No.
No.
Description
Qty
Parts List, Pointer Kit (P/N 05-0154)
1.
23-0228
ROD, INDICATOR
1
2.
30-0337
ROD, 1/4" DIA X 6
1
3.
30-0338
SLEEVE, CLAMP, 1/4"
1
46-0268
SLEEVE ASSY, ELBOW MDRL, 212B
1
4.
27-0365
ADAPTOR, SHAFT
1
5.
29-0252
BEARING, BALL
1
6.
33-0487
SCREW, SET, #10-24 X 3/16", CUP PT
1
7.
33-1750
SCREW, THUMB, BRASS, 1/4-20 X 1 1/2"
2
8.
46-0280
SLEEVE, INDICATOR
1
