PARTS LIST
BURNER ASSEMBLY FOR MODELS KC36NE, KC36PE, VKC36NE AND
VKC36PE
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 34 of this manual.
KEY
NO. PART NO.
DESCRIpTION
QTY.
1
116212-01 Burner Pan Assembly
1
2
116538-01 Base Grate
1
3
**
Bottom Firebox Base
1
4
26808
Valve Bracket
1
5
11107
Screw, #10-32 x 1/4 Zinc
4
6
**
Firebox Bottom
1
7
11102
Screw, #8-32 x 3/8 Zinc
2
8
116572-01 Aluminum Tubing Assembly
1
9
111288-02
Flex Gas Line
1
10
108866-01 Elec. Pilot Assembly (Natural)
1
108866-02 Elec. Pilot Assembly (Propane/LP)
1
11
14569
Elec. Valve Assembly (Natural)
1
14570
Elec. Valve Assembly (Propane/LP)
1
12
11165
Screw #10 x 5/8 Zinc
1
13
**
Burner Base Gasket
1
14
14396
Brass Fitting
2
15
116345-01 Pilot Bracket
1
16
26827
Switch Bracket
1
17
116573-01 Flat Washer, 7/8" ID x 1
1
/
4
" OD
2
18
11214
Bulkhead Fitting with Washer
1
19
14296
Elbow, 3/8"
1
20
116562-01 Gas Orifice #35 Natural
1
116564-01 Gas Orifice #51 Propane/LP
1
21
11186
Screw, #8 x 32 x 1 Zinc
2
22
110286-01 Ignition Module
1
23
11147
Screw, 10-24 x 1/2 BLK
2
24
14129
Transformer, 24V Class 2
1
25
116659-01 Crimp-on Terminal Ring
1
26
108863-01 24" Supply Connect Plug
1
27
14149
Spade 1/4 F RT. Angle
4
28
14126
16 GA Green Wire
1
29
14134
18 GA Black Wire
5
30
14120
Spade 1/4 Female Connector
4
31
17223
Magnet
2
32
23416
Electronic Components Board
1
33
11201
Nut, 8-32 Hex Zinc
4
** Not a field replaceable part.
