23 104461
OWNER’S MANUAL
PARTS LIST
SVYD18NR
FSVYD18NR
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed
under Replacement Parts on page 32 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 104026-01 Stove Log 1
2 103779-01 ODS Pilot (NG) 1
3 098249-01 ODS Nut 2
4 104423-01 Burner Outlet Tube 1
5 098264-02 Male Connector 1
6 102843-01 Burner Clip 1
7 099056-26 Burner Orifice Injector 1
8 102980-01 Burner 1
9 099387-15 Pilot Tube (Valve to regulator) 1
10 103781-01 Gas Control Valve 1
11 103345-02 Lower Bracket 1
12 M11084-38 Screw, #8 x .38 7
13 104383-02CK Painted Base Assy 1
14 098271-10 Ignitor Cable 1
15 102445-01 Piezo Ignitor 1
16 103587-02CK Plate, Switch 1
17 098304-01 Screw 2
18 103784-04 Flame Adjustment Knob 1
19 103784-03 Off-Pilot-On Knob 1
20 M12461-26 Screw, Hex Slt Wsr 10-32 x .38 4
21 100609-01 Pilot Tube (Regulator to Pilot) 1
22 099918-02 Pilot Regulator 1
23 103284-02 Wiring Harness 1
24 099998-01 Switch 1
PARTS AVAILABLE — NOT SHOWN
100563-01 Warning Plate 1
103877-01 Lighting Instructions Plate 1
100565-01 Warning Plate Fastener 1
101137-04 Hardware Kit 1
