www.desatech.com 114926-01B 19
PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 12 of this manual.
KEY PART NUMBER
NO. VTDMV24NA VTDMV24PA VTDMV18NA VTDMV18PA DESCRIPTION QTY.
1 111793-01 111793-01 111808-02 111808-02 Grate 1
2 111817-02 111817-02 111817-02 111817-02 Flexible Tube 1
3 099998-01 099998-01 099998-01 099998-01 Fan Switch 1
4 103784-02 103784-02 103784-02 103784-02 Knob Extension (HI/LOW) 1
5 103784-01 103784-01 103784-01 103784-01 Knob Extension (ON/OFF) 1
6 097159-04 097159-04 097159-04 097159-04 Piezo Ignitor 1
7 114942-01 114942-01 114942-01 114942-01 Heat Shield 1
8 111796-01 111796-01 111796-01 111796-01 Valve Bracket 1
9 111807-01 111807-02 111807-01 111807-02 Valve 1
10 112376-01 103778-01 112376-01 103778-01 Pilot Assembly 1
11 111828-01 111818-01 111828-01 111828-01 Brass Fitting 2
12 114930-01 114930-01 114930-01 114930-01 Pilot Bracket 1
13 26205 23109 26205 23109 Gas Orifice 1
14 114936-01 114936-01 114930-01 114930-01 Venturi 1
15 ** ** ** ** Burner 1
16 114933-02 114933-02 114933-01 114933-01 Plate Burner 1
17 ** ** ** ** Log Set 1
PARTS AVAILABLE NOT SHOWN
100563-01 100563-01 100563-01 100563-01 Warning Plate 1
103877-01 103877-01 103877-01 103877-01 Lighting Instruction 1
100639-01 100639-01 100639-01 100639-01 Caution Decal 1
GA6060 GA6060 GA6060 GA6060 Lave Rock 1
111228-02 111228-02 111228-02 111228-02 1/8" Flex Gas Line 1
114928-11 114928-12 114928-09 114928-10 Rating Plate 1
115597-01 115597-01 115597-01 115597-01 Log Repair Kit 1
112799-01 112799-01 112799-01 112799-01 Ember Flakes Kit 2
901242-01 901242-01 901242-01 901242-01 Damper Clamp 1
