F19
15 Amp Blue
Heating & Air
Conditioning
w/ATC Only
Battery Feed
F20
25 Amp Natural
Amplifier Bat-
tery Feed
Underhood Fuses (Power Distribution Center)
Cavity
Fuse/Color
Description
1
40 Amp
Green
HVAC Blower
2
30 Amp Pink Power Outlets
3
30 Amp Pink Rr Wiper/Ign R/O
4
30 Amp Pink ABS Pump
5
50 Amp Red
Cabin Htr 1 (Diesel Only)
6
50 Amp Red
ASD
7
30 Amp Pink Rr HVAC (XK)
Cavity
Fuse/Color
Description
8
40 Amp
Green
Acc Delay/Seats
9
Spare
10
40 Amp
Green
Starter/JB Power
11
30 Amp Pink Cig Ltr/T-Tow
12
40 Amp
Green
EBL/Htd Mirror
13
40 Amp
Green
JB Power
14
50 Amp Red
Cabin Htr 2 (Diesel Only)
15
50 Amp Red
Cabin Htr 3 (Diesel Only)
16
25 Amp
Natural
IPM/Coils
17
Spare
18
20 Amp Yel-
low
TCM/AC Clutch
MAINTAINING YOUR VEHICLE
345
7
