Power Distribution Center
Cavity Fuse Circuits
1 Cartridge
Fuse 40
Amp Batt-Relay Contact, High Blower
Motor Module-ABS Pump Feed
2 Cartridge
Fuse 40
Amp ABS Pump Feed
3 Cartridge
Fuse 30
Amp
Green Battery
4 Cartridge
Fuse 20
Amp Yel-
low Fused Feed to RS Amplifier or
Power Amplifier
Cavity Fuse Circuits
5 Cartridge
Fuse 30
Amp
Green Ignition Switch (Run &
Accessory)-(Downstream)
6 Cartridge
Fuse 40
Amp Batt
7 Cartridge
Fuse 30
Amp
Green Batt-Relay Contact, ABS Pump
Motor
8 Cartridge
Fuse 30
Amp
Green Batt-Motor, Wiper
9 Cartridge
Fuse 40
Amp Batt-Fuseblock
