15
Diagrams
HYDRAULIC PARTS LIST
REF # PART # DESCRIPTION QUANTITY
1 42-039 Front Wheel Motor (3 wheel drive only) 1
2 42-262 Hydraulic Hose (3 wheel drive only) 2
3 10-554 Hydraulic Cylinder 1
18-154 Rod End 1
HNJ-58-18 Jam Nut 5 /
8
- 18 1
4 42-047 Hydraulic Hose 2
5 13-729 2 - Bank Hydraulic Valve 1
78-417 Valve Handle 2
6 42-048 Hydraulic Hose 2
7 43-150 Hydraulic Cylinder 1
8 42-044 Hydraulic Hose 1
9 18-342 Cross 2
10 42-818 Hydraulic Hose 4
11 42-002 Rear Wheel Motor 2
12 42-259 Hydraulic Hose 10 3 /
4
" 1
15 42-599 Variable Pump 1
16 42-258 Hydraulic Hose 9" 1
17 8832-45 Suction Hose 1
18-222 Hose Clamp 2
18 42-787 Hydraulic Hose 1
19 23-006 Oil Filter 1
23-031 Replacement Filter Only
20 8832-24 Suction Hose 1
18-222 Hose Clamp 2
21 42-005 Oil Tank 1
13-747 Filler Breather 1
22 42-256 Hydraulic Hose 1
23 34-105 Oil Cooler 1
24 42-045 Hydraulic Hose 1
42-302 ELECTRIC ON/OFF VALVE KIT
25 42-263 Hydraulic Hose 2
26 76-260 Ground Wire 1
27 42-264 Hydraulic Hose 1
28 42-118 Electric On/Off Valve 1
29 18-185 Elbow 90° 1
30 18-341 Elbow 45° 3
36 42-838 Hydraulic Hose 1
HYDRAULIC PLOW
31 14-534 Hydraulic Cylinder 1
32 43-049 Hydraulic Hose 18" 1
34 43-048 Hydraulic Hose 20" 1
35 13-731 Single Bank Valve 1
HYDRAULIC PRESSURES
Pump Displacement .913 in 3 /rev Charge Pump Displacement .33 in 3 /rev
Pump Input Speed (up to) 3600 rpm Max. Inlet Vacuum 5 in. Hg
Max. Operating Pressure 2500 psi Max. Case Pressure 25 psi
Implement Setting 700-1000 psi Relief Valve Pressure (set at) 2500 psi
13-729 Hydraulic Valve (2 bank) 900 psi
