Cavity Car-
tridge
Fuse Mini-
Fuse Description
1 — 15 Amp
Blue Washer Motor
2 — 25 Amp
Neutral Powertrain Control
Module (PCM)
3 — 25 Amp
Neutral Ignition Run/Start
4 — 25 Amp
Neutral Alternator
5 — — —
6 — 25 Amp
Neutral Ignition Coils/Injectors
7 — — —
8 — 25 Amp
Neutral Starter
9 — — —
Cavity Car-
tridge
Fuse Mini-
Fuse Description
10 30 Amp
Pink — Windshield Wiper
11 30 Amp
Pink — Anti-Lock Brake System
(ABS) Valves
12 40 Amp
Green — Radiator Fan
13 50 Amp
Red — Anti-Lock Brake System
(ABS) Pump Motor
14 — — —
15 50 Amp
Red — Radiator Fan
16 — — —
17 — — —
18 — — —
19 — — —
MAINTAINING YOUR VEHICLE 373
