www.desatech.com 9 1749-01A
PARTS
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts, page 11.
KEY
NO.
PART NO. DESCRIPTION qTY.
1 118858-01 Table Top • 1
118858-0 Table Top • • 1
118866-01 Guard Rail • • • 3
3 118856-01 Deflector • • • 1
4 1155-01 Top Bracket • • • 3
5 11533-01 Upper Table Support Pillar • • • 3
6 1153-01 Lower Table Support Pillar • • • 3
7 118855-01 Table Decorative Grate, Mission • • 3
118855-0 Table Decorative Grate, Ornate • 3
8 118854-01 Deco Grate Pillar • • • 3
9 ––––– Emitter Assembly, see page 14 • • • 1
10 118859-01 Table Control Panel • 1
118859-0 Table Control Panel • • 1
11 118860-01 Table Door Panel • 1
118860-0 Table Door Panel • • 1
1 118851-01 Lower Table Panel • 1
118851-0 Lower Table Panel • • 1
13 119309-01 Pillar Support Connector • • • 3
14 118848-01 Table Heater Base • • • 1
15 118849-01 Wheel • • •
16 11886-01 Table Wheel Axle • • •
17 11965-01 Guard Rail Support Bracket • • • 3
18 119940-01 Screen • 3
19 118863-01 Ring Retainer • • •
PARTS AvAILABLE - NOT SHOWN
118988-01 Warning Decal • • • 1
11595-01 General Information Decal • • • 1
118990-05 Control Position Decal, English • • • 1
118990-03 Control Position Decal, Spanish/French • • • 1
11910-01 Regulator and Hose Assembly • • • 1
100639-13 Caution Decal • • • 1
11700-01 Hardware Blister Pack • • • 1
119110-01 Propane Tank Retention Chain • • • 1
10574-01 Retention Hook • • •
1194-01 Accessory Cover* • 1
TD101A, TD1
11A
TD103A TD109A
* Available as accessory for models TD101A, TD103A and TD111A.
