Dynacord Compact Mixing System - Manual (Page 8)

CMS 1000 CMS 1600 CMS 2200
Channels (Mono + Stereo) 6 + 4 12 + 4 18 + 4
Power Consumption max. 60 W max. 70 W max. 80 W
Dimensions, (WxHxD), mm 510.5x138x484.7 669.5x138x484.7 828.5x138x484.7
Weight 9.2 kg 11.9 kg 14,6 kg
MIC Gain (Mono) 0 dB … +60 dB
MIC Gain (Stereo) 10 dB … +60 dB
Stereo Line Trim -10dB … +20dB
THD+N at 1kHz, MBW=80kHz
MIC input to Main L/R output, +16 dBu, typical
< 0.005%
Frequency Response, -3dB ref. 1kHz
Any input to any Mixer output
15Hz … 55kHz
Crosstalk, 1kHz
Fader and AUX-Send attenuation
> 85 dB
Channel to channel > 80 dB
CMR, MIC input, 1kHz > 80 dB
Input Sensitivity, all level controls in max. position
MIC input
-74 dBu (155 µV)
LINE Input (Mono) -54 dBu (1.55 mV)
LINE Input (Stereo) -34 dBu (15.5 mV)
Maximum Level, mixing desk
MIC inputs
+ 21 dBu
Mono Line inputs + 41 dBu
Stereo Line inputs + 30 dBu
All other inputs + 21 dBu
Record Send output + 14 dBu
All other outputs + 21 dBu
Input Impedances
MIC
2 k Ohms
Insert Return 2.2 k Ohms
2 Track Return 8 k Ohms
All other inputs > 15 k Ohms
Output Impedances
Record Send
1 kOhm
Phones 47 Ohms
All other outputs 75 Ohms
Noise, Channel inputs to
Main L/R outputs, A-weighted
CMS 1000 / CMS 1600 / CMS 2200
Residual Noise, Master fader down -96 dBu / -96 dBu / -96 dBu
Bus Noise, Master fader 0 dB, Channel fader down -91 dBu / -90 dBu / -89 dBu
Mix Noise, Master fader 0 dB, Channel fader 0 dB,
Channel gain unity
-83 dBu / -83 dBu / -83 dBu
Equivalent Input Noise, MIC Input, A-weighted, 150 W -130 dBu
Equalization
LO Shelving
± 15 dB / 60 Hz
MID Peaking, mono inputs ± 15 dB / 100 Hz ... 8 kHz
MID Peaking, stereo inputs ± 12 dB / 2.4 kHz
HI Shelving ± 15 dB / 12 kHz
Master EQ, 2x7-band, 63, 125, 400, 1k, 2k5, 6k, 12k Hz ± 10 dB / Q=2.0
Mains Voltage 100 V – 240 V
Mains Frequency 50Hz – 60 Hz
Warranty 36 months
Optional
RMK-CMS (Rack-Mount-Kit CMS)
113 014
Gooseneck Lamp, 12V/2,4W, 12“, XLR 112 700
Replacement bulb, 12V/5W 350 278
FS11 (Footswitch) 110 693
©
