TECHNICAL - 2
TECHNICAL TECHNICAL
Example of computer signal
Resolution
H
× V
fH (kHz) fV (Hz) Rating Signal mode
Display
mode
720
× 400
37.9 85.0 VESA TEXT Zoom in
640
× 480
31.5 59.9 VESA VGA (60Hz) Zoom in
640
× 480
35.0 66.7 Mac13"mode Zoom in
640
× 480
37.9 72.8 VESA VGA (72Hz) Zoom in
640
× 480
37.5 75.0 VESA VGA (75Hz) Zoom in
640
× 480
43.3 85.0 VESA VGA (85Hz) Zoom in
800
× 600
35.2 56.3 VESA SVGA (56Hz) Zoom in
800
× 600
37.9 60.3 VESA SVGA (60Hz) Zoom in
800
× 600
48.1 72.2 VESA SVGA (72Hz) Zoom in
800
× 600
46.9 75.0 VESA SVGA (75Hz) Zoom in
800
× 600
53.7 85.1 VESA SVGA (85Hz) Zoom in
832
× 624
49.7 74.5 Mac16"mode Zoom in
1024
× 768
48.4 60.0 VESA XGA (60Hz)
1024
× 768
56.5 70.1 VESA XGA (70Hz)
1024
× 768
60.0 75.0 VESA XGA (75Hz)
1024
× 768
68.7 85.0 VESA XGA (85Hz)
1152
× 864
67.5 75.0 VESA SXGA (75Hz) Zoom out
1280
× 960
60.0 60.0 VESA SXGA (60Hz) Zoom out
1280
× 1024
64.0 60.0 VESA SXGA (60Hz) Zoom out
1280
× 1024
80.0 75.0 VESA SXGA (75Hz) Zoom out
• Some computers may have multiple display screen modes. Use of some of these modes
will not be possible with this projector.
• Be sure to check jack type, signal level, timing and resolution before connecting this projector to a
computer.
• Depending on the input signal, full-size display may not be possible in some cases. Refer to the
number of display pixels above.
• The image might be something wrong with computer by computer on the digital RGB mode. In the
case, it is recommended to reduce the resolution and / or reflesh rate.
NOTE
