6
P6 (DB9M) - Serial Input from computer
1 - DCD (connected to pins 4 & 6)
2 - Receive data from computer, connected to Pin2 of P3.
3 - Transmit data to computer, connected to Pin3 of P3.
4 - DTR (connected to pins 1 & 6)
5 - Ground
6 - DSR (connected to pins 1 & 4)
7 - RTS (connected to pin 8)
8 - CTS (connected to pin7)
CONTROLLER BOARD JUMPERS
(Located inside the drawer )
J1 - Connects to Input Power Jack for 12VAC @1A
JP1 - Not used
JP3 - Pin 1-2 to receive security code via Pin3 of P3, Pin3 of P6, Pin2 of P4 or
Pin2 of P5.
Pin 3-4* to receive security code via Pin2 of P3, Pin2 of P6, Pin3 of P4
or Pin3 of P5.
(*denotes factory default setting)
JP4 - Connects to solenoid, no polarity
JP5 - Connects to P3 for open-drawer indicator
1 collector, open-drawer indicator
2 emitter, open-drawer indicator
3, 4 ground
JP6 - Connects to optical interrupter
1 collector
2 cathode (ground)
3 emitter (ground)
4 anode
S1 - Set security code. Please refer to Figure 3.
S2 - Set RS232 protocol. Please refer to Figure 3.
S2 - BIT7 ON and BIT8 OFF for non-dedicated RS-232C.
S2 - BIT7 OFF and BIT8 ON for dedicated RS-232C.
