4
RaceAmerica Model 3220 Timer SBD
PACKAGE COMPONENTS
Each 3220 Series Timer SBD timing system
package includes:
1 - 3220D Series Console Unit
1 - IR Beam Emitter Model 5042
2 - IR Track Sensors Model 5140
1 - Interconnect Cable Assembly for
Track Sensors & Win Lights (option)
3 - Foam Stands (7540)
1 - 12VDC Power Patch Cord
1 - Owners Manual
POWER REQUIREMENTS
You will need these additional items to
operate your 3220 Series timing system:
1 - 12VDC automotive battery for Console
4 - ‘C’ batteries for Beam Emitter
NOTE: Operating the timer from a battery
connected to a charger or running car will result in
an over voltage condition and damage the timer.
PRODUCT SPECIFICATIONS
The following listing provides the designed
performance specifications for the 3220 Series
timing systems:
Lane Width 4 to 50 Feet
Differential Capacity up to 900.000 sec
ET Capacity
up to 900.000 sec
Time Accuracy 0.001 seconds
Model 3220 AVAILABLE OPTIONS
6220B Winning Lane Lights (qty 2)
6038S Dot-Matrix Timeslip Printer
6560/6860 Large Display (Win Lane/Delta)
and or Elapsed Time (ET)
06-S101 1000’ Start Cable/Switch
06-S102 1000’ Start Cable/Sensor/Emitter
4500B Data Communication PODs
(for peripherals >100ft - 2 req’d)
4520A/B Wireless RF Links (2 req’d)
6070B Carry/Storage Case
6502A AC Power Adapter
3120A AXWARE Derby Software
3120B AXWARE Derby + Race
Management S/W
3120C AXWARE Derby + Race
Management (AASBD) S/W
THEORY OF OPERATION
The 3220 Series Timers are completely
self contained race timing systems made
with CMOS circuit components to provide a
highly accurate timing solution. The system
contains an internal quartz crystal clock for
time accuracy and display of race results to
one thousandth of a second.
Power is supplied to the timer console
and track sensor components of the 3220 by
the 12VDC automotive battery connected to
the RED and BLACK alligator clips, cigarette
lighter adapter, or an AC adapter. An absolute
minimum of 11.0VDC is required for reliable
operation of the system. Under normal
conditions, charged batteries will operate for
days without a recharge.
The Beam Emitters and Track Sensors
operate on invisible (to the unaided human eye)
Infra Red light. The coded light frequencies
are constantly received by the Track Sensors
until a car interrupts reception (‘breaks’ the
beam).
The IR Beam Emitter to Track Sensor
transmission operates on Line-of-Sight
principles. This makes alignment of these units
critical. Tips are provided to aid alignment on
surfaces that are other than ideal. These units
will operate over a wide range of conditions
but should not be operated beyond the
specification parameters (less than 4 ft or more
than 50 ft).
Once the system is properly set up and
aligned, the timer console will ‘monitor’ the
track sensors each time a run is made.
