OPEN / CLOSE
INTERLACED / PROGRESSIVE
PLAY / PAUSE
STOP
SEARCH
HSD 415
DVD/CD/MP3 PLAYER
OPEN/CLOSE I/P PLAY/PAUSE STOP PREV NEXT
Front panel
Rear panel
POWER DISC TRAY
Note: 5.1 connectors not available in model HSD 310.
62
OUTPUTS AND CONTROL ELEMENTS
HDS 310 / HSD 415
ls
E
n
g
i
h
HSD 415
AV
VGA OUTPUT
VIDEO OUT
STEREO AUDIO OUTPUT RIGHT
STEREO AUDIO OUTPUT LEFT
DIGITAL OUT, COAXIAL
(5.1 MODE)
SURROUND (5.1 MODE)
(5.1 MODE)
AUDIO OUT FRONT RIGHT
AUDIO RIGHT
AUDIO OUT SUBWOOFER
AUDIO OUT CENTER
SURROUND AUDIO OUT LEFT
AUDIO OUT LEFT
YUV OUT (PROGRESSIVE SCAN ENABLED)
(5.1 MODE)
(5.1 MODE)
(5.1 MODE)
OPTICAL DIGITAL OUT
S-VIDEO OUT
VGA OUT
SCART
DISPLAY
