PARTS LIST
MODELS (V)k36N, (V)k36NH, (V)k36P AND (V)k36PH
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts
on page 28 of this manual.
k36N
k36P
Vk36N
Vk36P
k36NH
k36PH
Vk36NH
Vk36PH
DESCRIPtION
qtY.
110989-02
110989-01
111215-02
111215-01 Left Refractory Brick Panel
1
110991-02
110991-01
111217-02
111217-01 Rear Refractory Brick Panel
1
110990-02
110990-01
111216-02
111216-01 Right Refractory Brick Panel
1
kEY
NO.
PART NO.
DESCRIPtION
qtY.
1
**
Firebox Assembly
1
2
**
Face Weldment
1
3
108010-01
Door Assembly
1
108010-02
Door Assembly (V Models Only)
1
4
108011-01
Top Rolled Louver Assembly
1
5
108011-02
Bottom Rolled Louver Assembly
1
6
**
Fireplace Top
1
7
**
Fireplace Top Insulation
1
8
**
Fireplace Surround
1
9
109082-01
Heat Shield
1
10
111958-01
Log Set
2
10-1 111933-01
Left Base Log
1
10-2 111932-01
Right Base Log
1
10-3 111961-01
Left Front Log
1
10-4 111960-01
Right Front Log
1
10-5 111926-01
Right Rear Log
1
10-6 111929-01
Middle Crossover Log
1
10-7 111959-01
Left Rear Log
1
10-8 111930-01
Left Crossover Log
1
10-9 111962-01
Right Crossover Log
1
11
see below
Left Refractory Brick Panel
1
12
see below
Rear Refractory Brick Panel
1
13
see below
Right Refractory Brick Panel
1
14
108719-01
Screen Rod
1
15
12105
Screen
2
16
11418
Push-On Nut
2
17
14123
Strain Relief
1
18
21171
Gas Knock-Out Cover
2
19
24353
Handy Box Assembly
1
20
24460
Gas Conduit Assembly
1
21
111956-01
Burner Assembly (Natural Gas) (See pages 32 and 33)
1
111956-02
Burner Assembly (Propane/LP Gas)
PARTS AVAILAbLE - NOT SHOWN
25487
Lava Rock/Bag Assembly
1
27253
Notice Label
1
55240
Vent Label
1
** Not a field replaceable part.
