8/16 channel – OpenEye OE4 User Manual
Page 21
29060AB
9
16 Channel (240E)
8/16 Channel
BNC Connectors for Video Input
Cooling Fan
AC Power Connector
Looping Output Termination
Fire Wire
Audio
• Line In – line level
• Speaker Out
• Microphone In – not used
Sensors Inputs
SVGA Output
PS/2 Mouse Input
PS/2 Keyboard Input
DVI-D Port
Adapter for BNC Looping Output Cable
USB Ports
Control Outputs
Network Port
RCA Video Out
RS-485 Interface
BNC Connectors for Video Input
Cooling Fan
AC Power Connector
Looping Output Termination
FireWire
Audio
• Line In – line level
• Speaker Out
• Microphone In – not used
Sensors Inputs
SVGA Output
PS/2 Mouse Input
PS/2 Keyboard Input
DVI-D
Adapter for BNC Looping Output Cable
USB Ports
Control Outputs
Network Port
