X3 Rear Panel
16 Channel (240E)
AC power
BNC looping output cable adapter
Looping output termination
Video input (BNC)
Sensor inputs
Control outputs
RCA video out
Cooling fan
PTZ
Optical output
5.1 Surround sound
USB
USB
Network
eSATA
Line in – line level
Speaker out
Microphone in – not used
USB
HDMI
DVI-I
8/16 Channel
AC power
BNC looping output cable adapter
Looping output termination
Video input (BNC)
Sensor inputs
Control outputs
RCA video out
Cooling fan
PTZ
Optical output
USB
USB
Network
eSATA
USB
Audio input adaptor
5.1 Surround sound
Line in – line level
Speaker out
Microphone in – not used
HDMI
DVI-I
