TECHNICAL SPECIFICATIONS
Parameter Specification
Standards RS-232, RS-422, RS-485
RS-232 Data Rate 115.2kb/s max.
RS-422/RS-485 Data Rate 500kb/s max.
Transmission Distances RS-232 Port (Copper) - 15m
RS-485/422 Port (Copper) - 1500m
SM Optical Fiber - 20km
Optical Interface SC/UPC Connectors
Data Interface 8-bit Terminal Block
DC Input Voltage +9V
DC
(Min), +12V
DC
(Typ), +25V
DC
(Max)
Current Draw @ +12V
DC
80mA
Power Dissipation 1W (Typ), 2W (Max)
Operating Temperature Range -25 to +70°C
Weight 8.1oz. (230g)
Dimensions (L x W x H) 3.942" x 2.72" x 0.86" (100mm x 69mm x 22mm)
INSTALLATION
1. Connect the RS-232 or the RS422 or RS-485 interface to the Model OTDL-FOM-01 at the transmit end. Only one
format may be used at a time.
2. Connect the RS-232 or the RS422 or RS-485 interface to the Model OTDL-FOM-01 at the receive end. Only one for-
mat may be used at a time.
3. Connect the optical fibers to the optical interface on both the transmit and receive ends.
4. Apply power to the unit and check that the Power LED lights up. The RxD and TxD LED’s will light when all the ca-
ble connections are satisfactory.
