ENGLISH
Getting Started
q
POWER switch
• Press once to turn the power on.
• If a disc is loaded when the power is turned on, playback
starts automatically.
• Press again to set to the “OFF” position and turn the
power off.
w
Headphones Jack (PHONES)
• For private listening, you can connect your headphones
(commercially available)to this jack. Do not raise the
volume level too much when listening through
headphones.
e
Volume Control (PHONES LEVEL)
• Use this to adjust the output level of the headphones.
r
Remote control sensor
• This sensor receives the infrared light transmitted from
the wireless remote control unit.
• For remote control, point the supplied remote control
unit RC-1020 towards this sensor.
t
Display
( page 5)
y
Disc holder open/close button ( 5 )
• Press this button to open and close the disc holder.
u
SUPER AUDIO CD SETUP button
• Use this button to switch the layer of the Super Audio
CD and to set the top priority playback layer.
• The name of the newly set layer is shown on the display
each time the button is pressed.
STEREO:
The Super Audio CD’s layer (stereo) is played.
CD:
The CD layer is played.
✽ For details on “Setting the Top Priority Playback Layer
for Super Audio CDs” ( page 7).
i
PURE DIRECT button
• Both the digital output and the display are turned off. In
the PURE DIRECT mode, you can’t use the DISPLAY
button on the remote control unit function.
o
Automatic search forward button ( 9 )
• Press this button to move the pickup forward to the
beginning of the next track. Press again to move ahead
to other tracks.
!0
Automatic search reverse button ( 8 )
• Press this button to return the pickup to the beginning of
the present track. Press again to return to other tracks.
!1
Stop button ( 2 )
• Press this button to stop playback.
!2
Play/Pause button ( 1 / 3 )
• Press this button to start playback the disc.
• When pressed while the disc holder is open, the disc
holder closes and playback starts.
• Press this button to stop playback temporarily.
STEREO CD
!3
Disc holder
• Load discs here. ( page 7)
• Press the disc holder open/close button
y to open and
close the disc holder.
• The disc holder can also be closed by pressing the
play/pause button !2.
Part names and functions
!4
ANALOG OUT terminal
• Connect these to the amplifier’s input terminal.
• Connect using the included RCA pin-plug cord or a
commercially available connection cord.
!5
OPTICAL terminal
• Digital data is output in optical form from this terminal.
• Connect using an optical fiber cable (commercially
available).
✽ With Super Audio CDs, no digital signals are output.
!6
COAXIAL terminal
• This terminal outputs digital data.
• Connect using a 75 Ω/ohms coaxial pin-plug cord
(commercially available) intended for digital audio
connections.
✽ With Super Audio CDs, no digital signals are output.
!7
Power input (AC IN)
• Connect to an AC power supply using the included
power supply cord.
Front panel
Rear panel
