SM70 Rev. 4.00
TS100/TS200 Series PA Speakers Manual
Section 1 Description
1.1
Introduction
This manual contains information on the TS100WR and TS200WR PA Speakers. Some
TS100/TS200 Series PA Speakers information will also be provided for reference only.
Information in this section consists of purpose of equipment, features and specifications.
1.2
Purpose of Equipment
The TS100 and TS200 Series PA Speakers are lightweight loudspeakers that can be
used for both internal and external aircraft applications. The TS100WR/TS200WR Series
PA Speakers are used with the PA110, PA220 and PA250 series amplifiers.
1.3
Features
This series of speakers offers full 100- and 200-watt capability, and the driver assembly and
mechanical parts are field replaceable for ease of maintenance.
1.4
Specifications
1.4.1
Performance Specifications
Loudhailer
Input Power
Impedance
Frequency
Output Level @ 1m
TS100 (S-100S)
100 Wrms
11 Ohms
275 – 8000 Hz
116 dB (1 W, 1500 Hz signal)
TS100S (S-100R)
100 Wrms
11 Ohms
275 – 8000 Hz
114 dB (1 W, 1200 Hz signal)
TS100R (SD-210R)
100 Wrms
11 Ohms
275 – 7000 Hz
110 dB (1 W, 1000 Hz signal)
TS100A
100 Wrms
11 Ohms
275 – 7000 Hz
110 dB (1 W, 1000 Hz signal)
TS100WR
100 Wrms
11 Ohms
275 – 7000 Hz
110 dB (1 W, 1000 Hz signal)
TS200
100 Wrms
11 Ohms
275 – 7000 Hz
110 dB (1 W, 1000 Hz signal)
TS200WR
100 Wrms
11 Ohms
275 – 7000 Hz
110 dB (1 W, 1000 Hz signal)
Note: These specifications are given for guidance only. If further information is required,
please contact the Product Support department at NAT.
1.4.2
Physical Specifications
See the appropriate Mechanical Installation drawings (922-0) in Section 2 of this
manual for the PA Speaker physical specifications.
Mar 22, 2005
Page 1-1
