2.3.2
Cabling and Wiring
All unshielded wire shall be selected in accordance with AC43.13-1B Change 1,
Paragraphs 11-76 through 11-78. Wire types should be to MIL-W-22759 as specified in
AC43.13-1B Change 1, Paragraphs 11-85, 11-86, and listed in Table 11-11. For
shielded wire applications, use Tefzel MIL-C-27500 shielded wire with solder sleeves
(for shield terminations) to make the most compact and easily terminated interconnect.
Follow the wiring diagrams in Section 2.5 as required.
Allow 3 inches from the end of the wire to the shield termination to allow the backshell to
be easily installed.
All wiring should be at least 22 AWG, except power and ground lines, which should be
at least 20 AWG. Ensure that all ground connections are clean and well secured.
2.3.3 Post-Installation Checks
2.3.3.1 Voltage/Resistance Checks
Check the following:
a) P1
pin <1> for continuity to ground (chassis and DC power ground).
b) P1
pin <6> for +28 Vdc (panel lamps Hi).
c) P1
pin <15> for continuity to ground (panel lamps Lo).
d) P1
pin <16> for +14 or +28 Vdc (indicator bus).
e) P1
pin <17> for +5 Vdc (panel lamps Hi).
f) P1
pin <19> for +28 Vdc.
2.3.3.2
Power On Checks
a) Install the RGT-102 and power up the aircraft’s systems. Turn on the radios and
accessories required for the system.
b)
Run through all installed functions. Refer to Section 3 for operation details.
c)
Ensure that the unit and its mating connector are secured before departure.
Upon satisfactory completion of all performance checks, make the required log
entries and complete the necessary Regulatory Agency paperwork before
releasing the aircraft for service.
