AA38-3xx Series Local ICS Loop
SM37 Installation and Operation Manual
Section 2 Rev: 1.00 Issue 4 Page 2-5
ENG-FORM: 805-0117.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.
2.6 Accessories Required But Not Supplied
Installation kit p/n AA38-IKC (crimp) is required to complete the installation.
AA38-IKC consists of
Quantity Description NAT Part No.
1 D-min 37 Socket Housing 20-21-037
37 MS Crimp Socket 20-26-901
1* Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 37 Pin Connector Hood 20-29-038
* Use as required.
Note: Two kits will be required for the AA38-301.
2.7 Installation Drawings
DOCUMENT REV.
DESCRIPTION TYPE SERIAL NO.
AA38-300
AA38\300\403-0 1.00 Local ICS Loop Interconnect 1622 and up
AA38\300\405-0 1.00 Local ICS Loop Connector Map 1622 and up
AA38\300\521-0 1.02 Local ICS Loop Environmental Qualification Form 3000 and up
AA38\300\922-0 1.00 Local ICS Loop Mechanical Installation 1622 to 2999
AA38\300\922-0 1.10 Local ICS Loop Mechanical Installation 3000 to 3284
AA38\300\922-0 1.20 Local ICS Loop Mechanical Installation 3825 and up
AA38-301
AA38\301\403-0 1.00 16 Place Local ICS Loop Interconnect 2067 and up
AA38\301\403-1 1.00 16 Place Local ICS Loop Interconnect 2067 and up
AA38\301\405-0 1.00 16 Place Local ICS Loop Connector Map 2067 and up
AA38\301\922-0 1.02 16 Place Local ICS Loop Mechanical Installation 2067 and up
