AA21-400 Cabin PA System Manual SM34 Rev. 4.00
1.4.2 Physical
Specifications
Height 1.11 ± 0.03” (28.1 ± 0.8 mm)
Depth
6.53 ± 0.03” (165.9 ± 0.8 mm) behind panel (including
connector).
Width 4.96
± 0.03” (126.0 ± 0.8 mm) behind panel.
5.75 ± 0.03” (146.1 ± 0.8 mm) in front of panel.
Weight 1.40
± 0.07 lbs. (0.64 ± 0.03 kg)
Mounting
Std. Dzus Mounting (4 fasteners)
Faceplate
Engraved acrylic edge lit panel, with 28 Vdc backlighting.
Material/Finish
Chassis & cover: 5052-H32 brushed aluminum with
chromate conversion finish.
Heat sinks:
de-burred 6063-T6 aluminum with chromate
conversion finish.
Connector
Male filtered 25 pin D-subminiature with Positronics
V5 locking tabs.
1.4.3 Environmental
Specifications
Operating Temp -30 ° C to +55° C
Survival
Temp -55 ° C to +85° C
Humidity
> 95%
Altitude 25,000
ft.
DO-160D Env. Cat. B4-BAB[(SBM)(UF)]XXXXXXZBABB[TTX]MXXXX
TSO Compliance TSO-C50c, RTCA DO170 Class II
(Applicable to units Serial # 1200 and up)
