AA23 Speaker Amplifier Manual SM23 Rev. 4.00
AA23-IKS 15 Pin D-min Female Solder Kit (NAT Part # D15SL-IKS)
Quantity Description NAT Part #
1 D-min 15 Socket Solder Cup 20-20-015
1* Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 15 Pin Connector Hood 20-29-015
* Use as required.
1.6 Unit Nomenclature
Model
Description / Distinction
AA23-001
Accepts Mic., 600 Ω Line and H/S inputs, with floating interface.
Muted or partially muted outputs.
Dual PTT key logic inputs and outputs.
Selectable frequency response, Voice or Music.
Adjustable gain.
AA23-002
Accepts Mic. and two H/S inputs, with floating interface.
Muted or partially muted outputs.
Dual PTT key logic inputs and outputs.
Selectable frequency response, Voice or Music.
Adjustable gain.
End of section 1.0
