2.6 Installation Drawings
DRAWING REV. DESCRIPTION TYPE SERIAL #
AA24-001
AA24-001\40324001 - Single User Audio Controller Interconnect 1005 – 1127
AA24-001\403-0 1.01 Single User Audio Controller Interconnect 1128 and up
AA24-001\405-0 1.02 Single User Audio Controller Connector Map All
AA24-001\90324001 - Single User Audio Controller Mechanical 1005 – 1127
AA24-001\903-0 1.01 Single User Audio Controller 3-D 1128 and up
AA24-001\905-0 1.02 Single User Audio Controller (1 of 2) Faceplate All
AA24-001\922-0 1.01 Single User Audio Controller Mech. Installation All
AA25-001
AA25-001\403-0 1.00 Single User Audio Controller Interconnect 1001 – 1056
AA25-001\403-0 1.10 Single User Audio Controller Interconnect 1057 and up
AA25-001\405-0 1.02 Single User Audio Controller Connector Map All
AA25-001\905-0 1.01 Single User Audio Controller (1 of 2) Faceplate All
AA25-001\922-0 1.01 Single User Audio Controller Mech. Installation All
Section 2.0 ends after these Drawings
