AA31 ICS Mode Controller Manual SM10 Rev. 4.10
1.4 Specifications
1.4.1 Electrical Specifications
Input power: +28 Vdc
Power Requirements:
Nominal 155 mA max @ +27.5 Vdc
Lighting 80 mA max @ +27.5 Vdc
Annunciators:
REAR CALL (left) Amber (dimming)
REAR CALL (right) Amber (dimming)
ISO Amber (dimming)
COMMON Green (dimming)
Input Signals:
Quantity 4 ICS Tie Lines
2 Rear Call Lines
Circuitry Type Tie Lines are single ended
Output Signals:
Quantity 4 ICS Tie Lines,
2 Rear Call Lines,
4 Mode Annunciator Lines
Circuitry Type Tie Lines are single ended.
ICS Function Outputs (4) ALL ISO, REAR ISO, PILOT ISO, ALL COMMON.
AA31-001 Source 100 mA Max
AA31-002 Open Collector Output Sink 100 mA Max
1.4.2 Physical Specifications
Height 1.13" (28.7 mm)
Depth 2.82" (71.61 mm) behind panel
Width 4.90 (124.5 mm) behind panel
5.75" (146.1 mm) in front of panel
Weight 0.50 lbs. (225 g)
Mounting Panel mount Dzus rail (4 fasteners)
Faceplate Engraved acrylic edge lit panel.
Connectors Male 25-pin D-sub with jack screw fasteners
Material/Finish Chassis & cover are 5032-H32 brushed
aluminum with chromate conversion finish
Page 1-2 Feb 4, 2005
